OUR PROJECTS

A contemporary 5 bedroom dwelling spread over three floors with large open rooms offering spacious accommodation. Vector Structures were contracted to provide structural consultancy and worked closely with all relevant parties to ensure that the end product was built...

A stunning home renovation project in Berkshire involving a comprehensive transformation. This project featured a substantial double-story rear extension, a loft conversion, and major internal alterations. The goal was to create a modern, functional, and aesthetically...

A unique development scheme for one of the biggest house builders in the UK. This expansive project comprised 200 units spread across low-rise buildings and three flat blocks. Adding to the complexity, the scheme included a vehicle bridge, a timber pedestrian platform...

A new large modern home with very large spans and open vaulted rooms. The proposal required Vector Structures to couple both technical and artistic ability together to create a scheme that expressed the elegance of this beautiful property

Vector Structures were tasked with designing the structure for a new community centre spanning five floors, including a basement. The client's brief emphasized the creation of large, open spaces with no intermediate columns. The team achieved this by strategically...

A modern themed double storey side extension was designed to ensure large sliding doors could meet elegantly at the corner point, whilst also incorporating a large vaulted space on first floor level. Vector Structures acted as structural consultants and worked closely...

A development initiative for a distinguished homebuilder, renowned for selecting top-tier engineers in the industry for their projects. This 70-unit development comprises both low-rise structures and a substantial flat block. Vector Structures was commissioned to...

Vector Structures played a key role in constructing a multi-storey unit on a confined site, housing 10 flats. Entrusted with delivering a comprehensive structural package, Vector Structures also provided on-site support throughout the construction process. The new...

A prestigious client sought a luxurious 5-bedroom residence spanning 9000 sqft, featuring splendid vaulted spaces, a spacious central bridge, and a host of contemporary amenities. The location, nestled in one of Cookham's most sought-after areas, set the stage for an...

An outbuilding in the grounds of a Grade II* Listed rectory (One of the most prestigious rectories in Great Britain & a member of the Historic Houses of Britain). The outbuilding would be designed to contain offices for the client at the first-floor level and...

A New Modern Home Designed by Tait architects. Vector Structures were instructed to provide structural engineering drawings and calculations to help bring this structure to life

A small development of 4 homes which needed to be erected quickly as per the client’s brief. Vector Structures simple design aimed to reduce the number of steels as well as complex details so construction could be completed within the desired time frame. Vector...

Our client, a major pharmaceutical manufacturer, aimed to convert an existing building into a three-floor production facility, with the goal of doubling their turnover. Vector Structures devised a two-storey mezzanine structure to integrate into the building,...

Vector Structures were approached to design a structural solution for refurbishing this old previously converted tractor shed. The refurbishment led by one of our long-term architectural clients, would see the introduction of new openings, large glazed elements and...

A complete refurbishment project to an existing structure resulting in a full transformation of the external aesthetics. Large steel pans supported on columns and minimal masonry returns were needed as part of the architectural brief. Vector Structures were contracted...

A side and rear extension as well as major internal alterations. The rear extension features an open plan layout and a beautiful vaulted space. Vector Structures followed this project closely aiding the builder with any design queries and helping to alter and cater...

A relatively simple build turned disastrous when it was discovered that the site boundaries were smaller than initially anticipated by the client. Furthermore, the soil was soft clay and a massive public drainage network ran underneath the site leading Thames Water to...

A large double storey rear extension and lost conversion, Vector Structures were consulted to provide an effective solution that would be cost-effective to install whilst not effecting the integrity of the existing structure.

Vector Structures was entrusted with the task of formulating structural designs for the refurbishment and extension of a Grade II-listed terrace house, including its basement. The architectural significance of the Grade II classification, coupled with the close...

Amid the challenges posed by the COVID-19 pandemic, a multi-unit residential building consisting of seven flats was presented to Vector Structures with the intention of having a full structural design undertaking spanning over RIBA stages 3-5. The prevailing scarcity...

Vector Structures were consulted to provide the structural layout and structural details for a new 3 bedroom chalet bungalow. Working closely with both the build team and the architect, an efficient and cost effective scheme was produced. Close attention was paid to...

Vector Structures were consulted to work closely with a developer who to produce a design package for 4 new build homes. A major proportion of the design time was spent on the foundations and trying to make them economical and practical whilst ensuring stability to...

Working in close partnership with Network Rail UK, Vector Structures took on the responsibility of designing the structural system for a new platform walkway and ramp, facilitating convenient access from the underground railway tunnel to the Didcot Museum. The...

A lovely set of two homes on the outskirts of Maidenhead. Vector Structures produced a full set of plans and details and also provided onsite support to help the contractor complete the project in a swift manner.

A tricky loft conversion was required for this project in which the depth of the floor had to be drastically limited. Vector Structures used a clever set of steel frames to achieve this and detailed the floors intrinsically to mitigate vibration.

Three Large New Modern Home Designed by CP Homes Vector Structures were instructed to provide structural engineering drawings and calculations to help bring these structures to life

A complicated development of 8 luxury homes in Wales. Vector Structures was enlisted to provide a comprehensive structural package. The primary objective was to devise cost-effective solutions to support the substantial roof overhangs, cantilevered balconies, as well...

After a van had crashed into this property, Vector Structures were commissioned to inspect the damage and propose a scheme to repair the damaged superstructure.

A major refurbishment completely transforming the existing building into a large luxury dwelling. The refurbishment featured large open plan living spaces which required special attention and close collaboration with the architect to achieve the desired layout.

A complete renovation of existing property forming a 5-bedroom dwelling with elegant vaulted spaces, large open room and a stunning central staircase.

A luxury new build with a large roof plan and weak soil for the building to sit on posed interesting challenges for the vector team. Our expert engineers decided to use a mix of steel and timber to support the roof as this helped keep the build cost down but added the...

A new large modern home with very large spans and open vaulted rooms. The proposal required Vector Structures to couple both technical and artistic ability together to create a scheme that expressed the elegance of this beautiful property

A prestigious client sought a luxurious 5-bedroom residence spanning 9000 sqft, featuring splendid vaulted spaces, a spacious central bridge, and a host of contemporary amenities. The location, nestled in one of Cookham's most sought-after areas, set the stage for an...

Vector Structures were instructed to carry out inspection and design works for alterations to this manor home near the River Thames.

Vector Structures served as consulting engineers for a project involving the development of two luxury dwellings with scenic views near the sea. Situated into the hillside, both homes necessitated the construction of numerous retaining walls, including a significant...

A significant expansion and refurbishment encompassed a double-storey rear extension alongside substantial structural internal alterations. The project posed numerous challenges, notably adhering to the client's directive of maintaining a clear and open internal...
